X-rays that eminate towards the patient escape through an unshielded port in the tube housing. These form the useful or primary x-ray beam
The primary beam passes through filters that remove low energy x-ray photons that do not contribute to the imaging process.
The beam then travels until it interacts with the patient and is subsequently intercepted by an image receptor for processing and display.
|
